Networking from scratch: roadmap for future sysadmins

Learning networking is not about memorizing ports, acronyms, or commands. A system administrator needs to understand what happens to a packet from the moment an application sends it until it reaches its destination, where that path can fail, and how to prove what is happening.

This guide is a networking-from-scratch roadmap for future sysadmins. You can read it as an introduction, but it is designed primarily as a study plan: every stage builds on the previous one and ends with concrete skills you should be able to demonstrate before moving on.

You do not need enterprise hardware to begin. A computer, Linux, a few virtual machines, and tools such as Wireshark, VirtualBox, KVM, or Proxmox VE are enough to build an excellent lab.

Networking fundamentals for system administrators — Learning networking means understanding devices, protocols, services, and how to troubleshoot each layer of communication.

What you should be able to do after this roadmap

Explain how application data travels to another machine without relying only on memorized OSI layers.
Configure and troubleshoot IPv4 and IPv6 addresses, gateways, DNS, routes, and MTU.
Calculate IPv4 subnets and understand IPv6 prefixes.
Understand Ethernet, MAC addresses, ARP, NDP, VLANs, trunks, STP, and link aggregation.
Read a routing table and explain why a packet takes a particular path.
Distinguish TCP, UDP, and ICMP and relate them to sockets, ports, and services.
Administer networking on a Linux server from the command line.
Understand basic firewalling, NAT, VPN, and segmentation.
Use ping, tracepath/traceroute, dig, ss, tcpdump, Wireshark, and iperf3 for troubleshooting.
Understand virtual networking in hypervisors, containers, and cloud environments.
Document a network and apply a repeatable troubleshooting method.

Recommended roadmap

Stage	Goal
0. Build a lab	Linux, terminal, virtual machines, and basic binary concepts.
1. Physical and Ethernet	NICs, copper/fiber, MAC, switching, Wi‑Fi, speed, duplex, MTU.
2. IP addressing	IPv4, IPv6, CIDR, subnetting, gateways, ARP, and NDP.
3. Transport	TCP, UDP, ICMP, ports, sockets, state, and TLS.
4. Services	DNS, DHCP, NTP, HTTP(S), SSH, mail, SMB/NFS, and directory services.
5. Switching	VLANs, access/trunk ports, STP/RSTP, LACP, Layer 2 security.
6. Routing	Routing tables, static routes, OSPF, BGP concepts, NAT/PAT.
7. Security	Stateful firewalls, ACLs, segmentation, VPNs, secure administration.
8. Linux sysadmin	iproute2, NetworkManager, resolvectl, ss, nftables, tcpdump.
9. Virtualization and cloud	Bridges, vNICs, TAP/TUN, namespaces, containers, VXLAN.
10. Observability	Logs, SNMP, metrics, flows, packet capture, capacity.
11. Troubleshooting	A reproducible method from physical layer to application.
12. Automation	Git, Ansible, APIs, Python, and network as code.

Stage 0: build a lab before memorizing theory

Networking becomes much easier when you can observe packets and intentionally break things. Start with a small lab.

A computer with 8 GB RAM or more if possible.
VirtualBox, VMware Workstation, KVM/QEMU, or Proxmox VE.
Two or three Linux virtual machines; Debian or Ubuntu Server are enough.
Optionally, a virtual firewall/router such as pfSense or OPNsense.
Wireshark on your workstation and tcpdump inside the VMs.

You do not need to master Linux first, but you should be comfortable with the shell, files, permissions, processes, services, and a text editor.

Move on when: you can create two VMs on the same network, identify their interfaces, and verify connectivity between them.

Stage 1: physical layer, interfaces, and Ethernet

Before IP, understand what actually carries the bits: copper, fiber, and radio.

Copper Ethernet is inexpensive and common in LANs; cable category, distance, and transceivers constrain speed.
Fiber supports longer distances, high throughput, and immunity to electromagnetic interference; learn the basic difference between single-mode and multimode.
Wi‑Fi is a shared radio medium; coverage, interference, channel selection, channel width, and client count affect performance.

NICs, speed, duplex, and MTU

A NIC connects a host to the network medium. Modern Ethernet normally auto-negotiates speed and duplex, but negotiation problems can still produce loss and poor throughput.

The MTU is the largest unit that can cross a link without fragmentation. Ethernet commonly uses 1500 bytes, while tunnels and VPNs reduce the space available for the original packet. MTU problems can create confusing symptoms where ping works but some sites or transfers stall.

Ethernet frames and MAC addresses

Ethernet moves frames inside a Layer 2 domain. Switches learn which MAC addresses appear behind which ports and use that table to forward traffic efficiently.

Understand unicast, broadcast, and multicast, and remember that basic switching decisions are based on MAC addresses, not IP routing.

Move on when: you can explain what a switch learns, what a MAC address is, what MTU means, and why two hosts on the same LAN do not need a router to communicate.

Stage 2: IPv4, IPv6, CIDR, and subnetting

IP addressing and routing are core sysadmin skills because almost every service depends on them.

IPv4

Host address.
Subnet mask or prefix length.
Network address.
Usable host range.
Broadcast address.
Default gateway.
RFC 1918 private ranges versus public space.
Loopback and link-local addressing.
CIDR and route summarization.

For example, 192.168.10.34/24 belongs to 192.168.10.0/24. A /24 reserves 24 bits for the network and leaves 8 bits for addresses within that network.

Do not skip subnetting

Starting from 192.168.10.0/24, four equal-size subnets can be created using /26:

192.168.10.0/26
192.168.10.64/26
192.168.10.128/26
192.168.10.192/26

Each block contains 64 addresses. Traditional IPv4 subnets reserve network and broadcast addresses, with special cases for certain point-to-point designs.

IPv6 is not optional

Global unicast addresses.
Link-local fe80::/10.
Loopback ::1.
Common /64 LAN prefixes.
Neighbor Discovery and Router Advertisements.
SLAAC and DHCPv6.
AAAA DNS records.
The fact that IPv6 does not use broadcast in the IPv4 sense.

ARP and NDP

IPv4 uses ARP to discover the MAC address associated with a local IPv4 address. IPv6 uses Neighbor Discovery Protocol, based on ICMPv6, for neighbor and router discovery.

Move on when: you can determine whether two hosts are in the same subnet, calculate several IPv4 subnet sizes, explain the role of the default gateway, and recognize IPv6 link-local and global addresses.

Stage 3: ICMP, TCP, UDP, ports, and sockets

ICMP

ICMP is more than ping. It carries network control information such as unreachable destinations, time exceeded, and MTU-related conditions. ICMPv6 is fundamental to normal IPv6 operation.

TCP

Three-way handshake: SYN, SYN-ACK, ACK.
Sequence and acknowledgement numbers.
Retransmissions.
Windows and flow control.
Congestion control as a concept.
Connection teardown.
States such as LISTEN, ESTABLISHED, TIME_WAIT, and CLOSE_WAIT.

UDP

UDP sends datagrams without a TCP-style connection and does not guarantee delivery, ordering, or retransmission. Reliability can be implemented by the application when needed. DNS, voice, video, and QUIC are common examples where UDP may be part of the solution.

Ports and sockets

ss -tulpn
ss -tan
ss -uan

Move on when: you can explain why one server IP can simultaneously provide SSH, HTTPS, and DNS, and identify an established TCP connection in ss.

Stage 4: services every sysadmin should know

DNS

DNS is a distributed database. Learn recursive versus authoritative resolution and records such as A, AAAA, CNAME, MX, NS, PTR, TXT, and SRV.

dig universodigital.org
dig A universodigital.org
dig AAAA universodigital.org
dig MX example.com
dig +trace example.com

DHCP

DHCPv4 can provide addressing, gateway, DNS, and other parameters. Learn the DORA flow—Discover, Offer, Request, Acknowledge—and understand leases, reservations, scopes, and DHCP relay.

NTP and other services

Correct time is infrastructure. TLS, Kerberos, logs, clusters, and event correlation all become harder or unreliable when clocks drift.

HTTP/HTTPS and TLS.
SSH and SFTP/SCP.
SMTP and IMAP basics.
SMB/CIFS and NFS.
LDAP and Active Directory concepts.
SNMP for monitoring.
Syslog and journald.
Database services and the difference between listening locally and exposing a port to the network.

Move on when: when a service “does not open,” you can separate DNS, IP reachability, routing, firewalling, listening port, and application behavior.

Stage 5: real switching—VLANs, trunks, STP, and LACP

A VLAN creates an independent Layer 2 broadcast domain on shared infrastructure. An access port normally carries one VLAN for an endpoint, while a trunk can carry multiple VLANs using IEEE 802.1Q tags.

Hosts in different VLANs require routing to communicate. VLANs segment Layer 2; they do not replace a firewall.

STP and RSTP

Layer 2 loops can create broadcast storms and unstable MAC tables. Spanning Tree Protocol and its variants block redundant paths to keep Ethernet topologies loop-free.

Link aggregation

LACP can bundle physical links into one logical interface when both ends support it. This can add redundancy and spread flows, but a single TCP flow does not automatically gain the sum of all member-link speeds.

Layer 2 security

Managed networks may use DHCP snooping, Dynamic ARP Inspection, RA Guard, port security, and storm control. Current CCNA objectives include these topics because Layer 2 mistakes and attacks can affect both security and availability.

Move on when: you can design user, server, and management VLANs and explain where inter-VLAN traffic is routed and filtered.

Stage 6: routing, routing tables, and NAT

ip route
ip -6 route
ip route get 1.1.1.1

Learn connected routes, static routes, default routes, dynamically learned routes, metrics, and longest-prefix matching.

Static and dynamic routing

Start with static routing. Then learn OSPF to understand an interior routing protocol. Study BGP later as the protocol used to exchange reachability between autonomous systems and as a core part of Internet routing.

NAT and PAT

NAT rewrites addresses. PAT lets many private IPv4 hosts share one public IPv4 address by differentiating flows with ports. NAT is not a firewall, even when both functions run on the same device.

Move on when: you can read a routing table and predict which gateway or interface will be used for several destinations.

Stage 7: firewalls, segmentation, and VPNs

A modern firewall normally tracks connection state. Think in terms of source, destination, protocol, port, direction, and state—not simply “open port 443.”

Apply least privilege: expose only what is required and separate trust zones when risks differ.

WireGuard, IPsec, and OpenVPN can create protected tunnels for remote access or site-to-site connectivity. Learn routing, DNS, and MTU behavior inside tunnels as well as encryption.

For practice, see our pfSense introduction.

Stage 8: Linux networking for sysadmins

Interfaces and addresses

ip -br link
ip -br addr
ip addr show

Routing

ip route
ip route get 1.1.1.1
ip -6 route

Neighbors

ip neigh

Sockets and processes

ss -tulpn
ss -tanp

DNS

resolvectl status
resolvectl query universodigital.org
dig universodigital.org

NetworkManager

Many Linux distributions use NetworkManager. Red Hat documents nmcli and nmtui for administration, including headless systems.

nmcli device status
nmcli connection show
nmcli -f GENERAL,IP4,IP6 device show

Ethernet state

ethtool eth0

Packet capture

sudo tcpdump -ni any
sudo tcpdump -ni eth0 port 53
sudo tcpdump -ni eth0 host 192.168.1.50

Wireshark can open pcap and pcapng captures and dissect protocols visually. Being able to read a simple packet capture is one of the most useful sysadmin troubleshooting skills.

Performance testing

iperf3 -s
iperf3 -c SERVER_IP

Local firewalling with nftables

Modern Linux administrators should understand nftables and Netfilter connection tracking. Distribution tools such as firewalld or UFW can simplify policy management, but knowing the underlying model remains valuable.

Move on when: you can repair VM networking, identify which process listens on a port, test DNS, inspect the routing decision, and capture packets for a failing connection.

Stage 9: virtualization, containers, and cloud networking

Modern sysadmins work with virtual interfaces as often as physical ones.

Bridges and virtual NICs

A Linux bridge behaves conceptually like a software switch. Hypervisors such as KVM and Proxmox VE attach VM interfaces to bridges, VLANs, and physical networks.

TAP, TUN, namespaces, and veth

TAP transports Layer 2 Ethernet frames.
TUN transports Layer 3 IP packets.
Linux network namespaces provide isolated network stacks.
veth pairs connect namespaces and are fundamental to container networking.

Docker, Podman, and Kubernetes build virtual networks, bridges, NAT, and policy on top of these fundamentals. Learn routing, NAT, DNS, and namespaces before diving deeply into Kubernetes networking.

VXLAN and other overlays can carry Layer 2-like segments across Layer 3 networks. Study them after you are comfortable with VLANs and routing.

Our Proxmox VE articles provide practical scenarios for bridges, VLANs, and VM networking.

Stage 10: observability and capacity

Availability and latency.
Interface utilization and physical errors.
Packet loss.
Bandwidth saturation.
Jitter for voice/video.
Device CPU and memory.
Routing or link changes.
Firewall, switch, router, and server logs.
Traffic flows through NetFlow/IPFIX when available.

SNMP, syslog, Prometheus/Grafana, Zabbix, LibreNMS, and similar platforms can provide visibility. The specific product matters less than learning to establish a baseline and detect deviations.

Bandwidth, throughput, latency, jitter, and loss

Bandwidth: theoretical or configured link capacity.
Throughput: actual amount of data transferred per unit of time.
Goodput: useful application data after protocol overhead and retransmissions.
Latency: travel time across the path.
Jitter: variation in delay.
Loss: packets that never reach the destination.

A 1 Gbit/s link can feel worse than a 100 Mbit/s link for interactive traffic when latency, jitter, or loss are high.

Stage 11: build a troubleshooting method

Does the interface exist and is it UP? Check ip link.
Does it have the correct address and prefix? Check ip addr.
Can it reach a host on the local subnet?
Does ARP/NDP resolve the neighbor? Check ip neigh.
Is there a route? Use ip route get DESTINATION.
Can it reach the gateway?
Can it reach a remote IP address?
Does DNS return the correct answer? Use dig.
Is the application port listening? Use ss.
Does firewall/NAT allow the flow?
Does the application respond correctly?
If unclear, capture packets at the right points and identify where the traffic disappears or changes.

Ping is useful, but do not turn it into the only test. A host may block ICMP Echo and still serve HTTPS, while a successful ping proves nothing about DNS, TCP 443, TLS, or the application.

Tool	Purpose
ip	Interfaces, addresses, neighbors, and routes.
ping	Basic ICMP reachability and latency.
tracepath / traceroute	Path and hops to a destination.
mtr	Observed latency and loss along a path.
dig	DNS queries and troubleshooting.
ss	Sockets and listening ports.
tcpdump	Command-line packet capture.
Wireshark	Detailed packet analysis.
ethtool	Ethernet link state and features.
iperf3	Point-to-point performance testing.
nft	nftables/Netfilter rules.
curl	HTTP/HTTPS and application-layer tests.
openssl s_client	Basic TLS and certificate troubleshooting.

Stage 12: automation and Network as Code

Learn to automate only after you understand the manual operation. Automating something you do not understand simply lets you make mistakes faster.

Git for configuration and documentation history.
Ansible for repeatable changes.
Python for APIs, validation, and tooling.
JSON/YAML and structured data.
APIs exposed by controllers, firewalls, clouds, and hypervisors.
Infrastructure as code and pre-change validation.
Automated configuration backups.

Modern professional networking objectives increasingly include controller-based management, APIs, automation, and infrastructure as code. CLI skills remain important, but network operations are progressively becoming software-driven.

12 labs to complete the roadmap

Connect two VMs on one LAN, assign static IPv4 addresses, and prove connectivity.
Capture ARP and then a TCP three-way handshake in Wireshark.
Split a /24 into four /26 networks and build two of them in your lab.
Configure IPv6 and observe Neighbor Discovery with tcpdump/Wireshark.
Run a DNS server or use BIND/dnsmasq and create A and AAAA records.
Run DHCP and provide gateway and DNS settings to a test LAN.
Create user, server, and management VLANs and route them through a firewall/router.
Allow only HTTPS from the user VLAN to one server and block other inter-VLAN traffic.
Build a WireGuard VPN between two VMs or lab networks.
Measure throughput with iperf3 and observe latency/throughput changes under load.
Build two networks in Proxmox/KVM using bridges and VLAN tags.
Intentionally break DNS, gateway, prefix, firewall, and MTU settings and document how you diagnosed each failure.

What to study after the fundamentals

Linux administration: systemd, NetworkManager/netplan, nftables, bonding, bridges, HA, services.
Enterprise networking: advanced switching, OSPF, BGP, redundancy, QoS, NAC, enterprise Wi‑Fi.
Security: firewalls, IDS/IPS, PKI, TLS, VPNs, segmentation, traffic analysis.
Virtualization: KVM, Proxmox VE, VMware, overlays, storage, high availability.
Cloud: VPC/VNet, routing, security groups, gateways, load balancers, hybrid connectivity.
Containers: Docker/Podman networking followed by Kubernetes CNI, Services, Ingress, and NetworkPolicy.
Automation: Ansible, Python, APIs, GitOps, infrastructure as code.

Certifications such as CCNA or CompTIA Network+ can help organize your learning, but they are not a replacement for a lab. Use their objectives as checklists rather than as the boundary of what you should understand.

Common beginner mistakes

Memorizing OSI layers without relating them to real traffic.
Skipping subnetting because calculators exist.
Learning only IPv4 and treating IPv6 as optional.
Confusing NAT with firewalling.
Confusing bandwidth with perceived performance.
Changing many variables at once during troubleshooting.
Solving permission issues with 777 or network problems by permanently disabling the firewall.
Memorizing commands without knowing which hypothesis each command tests.
Failing to document addresses, VLANs, gateways, DNS, and changes.

How to know you have a solid sysadmin networking foundation

You do not need every RFC memorized. You have a solid base when someone says “the server cannot be reached from another VLAN” and you can form a logical sequence of questions: does it have the right address and prefix, is there a gateway, does the route exist, does ARP/NDP work, does the firewall allow the flow, is the service listening, does DNS point to the right place, and what does the packet capture show?

That transition—from trying random fixes to reasoning about the traffic path—is the real objective of learning networking for systems administration.

S	M	T	W	T	F	S
				1	2	3
4	5	6	7	8	9	10
11	12	13	14	15	16	17
18	19	20	21	22	23	24
25	26	27	28	29	30	31

Autores

Eidy y Yirenia
